Performance
- Temperature range from ambient +5℃ to 100℃.
- Microprocessor PID control / Automatic tuning / Calibration.
Convenience
- Easy readout digital LED displays. (0.1℃resolution)
- Dual wait on/off timer modes. (1 min. to 99 hr. 59 min.)
- Programming functions are ideal for critical research quality control, and regulatory tests.
- Convenient memory function of up to three frequently set temperature.
- Corrosion-resistant stainless steel construction allowing other bath fluids as well as water and silicone fluids.
- Low-profile reservoir design.
Safety
- Isolated design of heater, and sensor by a baffle plate to protect users and samples against direct contact.
- Complete safety protection system with warning alarms.
- Low fluid level and dry-running, over-temperature, over-current.
- Splash-proof keypad.
Available Accessories & Options
- Transparent Polypropylene Gable Covers - prevent liquid loss due to evaporation, and also protect samples from contamination due to direct dripping of the bath liquid into the samples. The gable type roof accommodates glassware of varying heights
- Stainless Steel Flat Covers - Made of stainless steel to prevent corrosion and rust. (only for BW-H and BW-B Models)
- Open-rings Covers - Beakers or Erlenmeyer flasks can be placed directly onto the perforated stainless steel half-shelf adjuster or water tank bottom. By adjusting ring size for each glassware, liquid loss due to evaporation is minimized. (only for BW-H, BW-B, BW-G Models)
- Test Tube Racks - Highly durable stainless steel test tube racks feature adjustable angle and tube height support without requiring any base plate. You can easily mount and release test tube racks.
- Spring Wire Racks - Ideal for holding a wide variety of tubes, flasks, and other glassware. All components are made of stainless steel. (for all models)
- Half-shelf Adjusters - Stainless steel perforated sample tray shelves with adjustable height support prevent leaks and guard against rust and contamination. (only for BW-H, BW-B, and BW-G Models)
| Model |
BW3-05G |
BW3-10G |
BW3-20G |
|
Bath volume (L / cu ft)
|
3.5 / 0.1
|
11.5 / 0.4
|
20 / 0.7
|
|
Working temperature range (℃ / ℉)
|
Amb. +7 to 100 / Amb. +12.6 to 212
|
|
Temperature stability 1) (±℃ / ℉)
|
0.4 / 0.72
|
0.3 / 0.72
|
0.3 / 0.72
|
|
Dimension
|
Bath opening / depth (W×L, D) (mm / inch)
|
240×136, 150/ 9.4×5.4, 5.9
|
300×240, 200/ 11.8×9.5, 7.9
|
498×300, 200/ 19.6×11.8, 7.9
|
|
Exterior with gable cover (W×L×H) (mm / inch)
|
307×200×264/ 12.1×7.9×10.4
|
360×300×294 / 14.2×11.8×11.6
|
564×356×294 / 22.2×14×11.6
|
|
Net weight (kg / lbs)
|
6.5 / 14.3
|
10 / 22
|
18.5 / 40.8
|
|
Electrical requirements (230V, 50 / 60Hz)
|
3A |
4.3A |
8.7A |
|
Cat. No.
|
AAH41305K |
AAH41315K |
AAH41325K |
1) Technical data according to DIN 12876. (bath fluid : water at 50℃)
