Absorption measuring range
|
0 A – 3.0 A (260 nm)
|
BSA concentration range
|
7.5 ng/µL – 45.45 µg/µL
|
BSA concentration range (UV 280 nm) µCuvette G1.0
|
75 ng/µL – 45.45 µg/µL ±0.03 µg/µL at A = 0 ±0.076 µg/µL at A = 1 (0.5 %)
|
BSA concentration range (UV 280 nm) UVette 10 mm
|
7.5 ng/µL – 4.5 µg/µL ±0.003 µg/µL at A = 0 ±0.007 µg/µL at A = 1 (0.5 %)
|
BSA concentration range (UV 280 nm) UVette 2 mm
|
37.5 ng/µL – 22.5 µg/µL ±0.015 µg/µL at A = 0 ±0.038 µg/µL at A = 1 (0.5 %)
|
Beam receiver absorption
|
CMOS photodiodes
|
Cuvette shaft
|
12.5 mm × 12.5 mm
|
Light path height
|
8.5 mm
|
Light source absorption
|
Xenon flash lamp
|
Measuring principle absorption
|
Single-beam absorption photometer with reference beam
|
Method memory
|
>100 method programs
|
Operator guidance language
|
Spanish, Italian, French, English, German
|
Power consumption
|
Approx. 15 W during operating step Approx. 5 W with dimmed display
|
Random error absorption
|
≤0.002 at A = 0 ≤0.005 (0.5 %) at A = 1
|
Random error wavelength
|
±1 nm
|
Spectral bandwidth
|
≤4 nm
|
Systematic error absorption
|
±1 % (A = 1)
|
Systematic error wavelength
|
≤0.5 nm
|
Wavelength range absorption
|
Fixed wavelength (nm): 230, 260, 280, 320, 340, 405, 490, 562, 595, 600
|
Wavelengths
|
230, 260, 280, 320, 340, 405, 490, 562, 595, 600 nm
|
dsDNA concentration range
|
2.5 ng/µL – 1,500 ng/µL
|
dsDNA concentration range (UV 260 nm) UVette 10 mm
|
2.5 ng/µL – 150 ng/µL ±0.1 ng/µL at A = 0 ±0.25 ng/µL at A = 1 (0.5 %)
|
dsDNA concentration range (UV 260 nm) UVette 2 mm
|
12.5 ng/µL – 750 ng/µL ±0.5 ng/µL at A = 0 ±1.25 ng/µL at A = 1 (0.5 %)
|
dsDNA concentration range (UV 260 nm) µCuvette G1.0
|
25 ng/µL – 1,500 ng/µL ±1 ng/µL at A = 0 ±2.5 ng/µL at A = 1 (0.5 %)
|
Interfaces
|
› USB master: for USB stick and thermal printer DPU-S445 › USB slave for connecting to a PC › Serial interface RS-232: for thermal printer DPU-414 › Ethernet interface RJ45: For connecting to a network printer
|
Power supply
|
100 – 240 V, 50 – 60 Hz
|
Dimensions (W × D × H)
|
295 × 400 × 150 mm / 11.6 × 15.7 × 6 in
|
Weight w/o accessories
|
5.4 kg
|
