Performance
- Temperature range from ambient +3°C to 60°C.
- Microprocessor PID control / Temperature calibration / Automatic tuning.
- Vibration-free design ideal for yeast cultivation.
- Free from noise, vibration, and mechanical troubles by film type heating method.
Convenience
- Intuitive control panel with bright LED display. (0.1℃resolution)
- Dual wait on/off timer modes. (1 min. to 99 hr. 59 min.)
- Convenient preset function for 3 most commonly used temperature settings.
- Convenient sample monitoring without affecting chamber temperature via the inner tempered-glass door.
- Rounded inner chamber corners for easy cleaning and optimal airflow.
- Stackable up to 2 units using the optional stacking kit. (optional)
Safety
- Automatic run after power interruption.
- Keypad lock function prevents accidental changes during operation.
- Over-temperature and over-current protection.
- Audible and visible open door alarms.
Available Accessories & Options
- Wire shelves - Stainless steel and electro-polished shelves are readily removed without using tools for easy cleaning.
- Perforated shelves - Stainless steel shelves are readily removed without using tools for easy cleaning.
- Stacking kits - Stackable up to 2 units using exclusive stacking kits for space saving.
| Model |
IB-01E |
IB-11E |
IB-21E |
| Chamber volume (L / cu ft) |
65 / 2.3 |
150 / 5.3 |
205 / 7.2 |
| Temperature |
Range (℃ / ℉) |
Amb. +3 to 60 / Amb. +5.4 to 140 |
| Fluctuation 1) at 37℃ (±℃ / ℉) |
0.2 / 0.36 |
0.3 / 0.54 |
0.1 / 0.18 |
| Variation 1) at 37℃ (±℃ / ℉) |
0.6 / 1.08 |
0.8 / 1.44 |
1.1 / 1.98 |
| Dimension (W×D×H) |
Interior (mm / inch) |
423×355×445
/ 16.7×14×17.5
|
500×515×585
/ 19.7×20.3×23
|
632×515×630
/ 24.9×20.3×24.8
|
| Exterior (mm / inch) |
533×475×725
/ 21×18.7×28.5
|
595×630×865
/ 23.5×24.8×34
|
740×630×910
/ 29.1×24.8×35.8
|
| No. of wire shelf (standard/ max.) |
2 / 10 |
2 / 13 |
2 / 14 |
| Net weight (Kg / lbs) |
33 / 72.8 |
47 / 103.6 |
57 / 125.7 |
| Electrical requirements (230V, 50 / 60Hz) |
1.1A |
2.2A |
2.4A |
| Cat. No. |
AAH26015K |
AAH26025K |
AAH26035K |
1) Technical data according to DIN 12880.
