A great deal of time, effort and research has gone into the production of BlackStone Pumps, making sure they are manufactured to the highest level of mechanical precision, capable of resisting the negative effects of most aggressive chemicals.
The low-maintenance BlackStone range covers a wide spectrum of dosing capacities and all made with positive displacement solenoid driven pumps that use a minimum number of moving parts, therefore reducing the risk of mechanical failure and ensuring each stroke is identical for a consistent flow rate. (Scroll down for a full list of materials used in the pump’s construction.)
Each pump measures 194 x 165 x 121 mm (7.6 x 6.5 x 4.8 inches), and weighs 3 kg (6.6lb). Installation has been made easy with ready-drilled holes for horizontal or vertical mounting. Easy operation has also been considered with a single control for pump output.
*IP65 (International Protection Rating) equals dust tight and water jet protected.
Accessories available:
- HI-721004 Injection Valve assembly
- HI-721005 Foot valve assembly
- HI721101 Pump head, O-ring, screws and washer
- HI-721102 Discharge valve assembly
- HI-721103 - Suction valve assembly
- HI-721008 - Ceramic weight (4)
- HI-720011D - Magnet and coil for BL Pumps (230VAC)
- HI-720011U - Magnet and coil for BL pumps (115VAC)
- HI-720025 - Pump body
- HI-720034 - Magnet pump head assembly for BL pumps
- HI-721001 - Complete pump head with valves
- HI-72001 - Tube nut, 5 x 8 mm dia. (100 pcs)
- HI-721009 - Diaphragm
- HI-721010 - PTFE coated O-ring for pump head
- HI-721011 - Aluminium piston, insulation disk, washer and springs replacement kit for BL pump
- HI-721013 - Piston set for BL pump
- HI-721014 - Bottom housing and housing seal
- HI-721104 - Small diaphragm for BL pumps
- HI-721105 - BlackStone spare pump head
- HI-721106 - BlackStone pump head assembly
Materials used in a BlackStone Chemical Dosing Pump's construction:
- Pump head in PVDF (Polyvinylidene Fluoride)
- Diaphragm - a one-piece construction made from the very resistant PTFE (Polytetrafluoroethylene).
- Ball valves - glass
- O-rings - FPM/FKM (Fluoro Rubber)
- 5 x 8mm polyethylene tubing
